ʻO Kina ka mea hana pahu hoʻolaha ʻoihana

Hoʻokaʻawale

ʻAno

Lahui o keia manawa

Nā ʻano nui

Ma ka maʻamau (IEC 61439)

IEC 61439-3 (DBO)

≤250A

Hoʻohana ʻia nā papa hoʻolaha e nā kānaka maʻamau, hale / kalepa, nā kaapuni puka ≤125A

IEC 61439-2 (PSC)

≤6300A

ʻO nā hui hoʻololi mana, ʻoihana, hana ʻoihana wale nō

IEC 61439-4 (ACS)

≤1000A

ʻO nā hui no nā kahua kūkulu, no ka manawa pōkole, hiki ke lawe ʻia/mobile

IEC 61439-5

≤2500A

ʻO nā pūnaewele hoʻolaha lehulehu, nā keʻena hoʻolaha kelepona

IEC 61439-7

ʻokoʻa

Nā noi kikoʻī: marinas, EV charging, market square

Ma ke kau ana

Paʻa i ka pā

≤630A

Ke kau ʻana o ka ʻili a i ʻole ka flush, IP30-IP65, hale noho/kalepa

Kū i ka papahele

≤6300A

Kū kūʻokoʻa, kūkulu modular, nā kikowaena ʻoihana/mana

pou-kau

≤400A

ʻO ka hāʻawi ʻana i waho, nā kukui ākea, ka uila uila

Ma ke kukulu ana

Metala i hoʻopaʻa ʻia

Nā papa helu a pau

Ke kila / Aluminum, IP30-IP65, pale electromagnetic

Nā pā i hoʻopaʻa ʻia

≤250A

Thermoplastic (ABS, PC), IP40-IP65, pale ʻino

Pūnaehana modular

≤630A

Hoʻopili ʻia ka DIN rail, 17.5mm modularity, hoʻonohonoho maʻalahi

Ma ke noi

Hale noho

≤250A

Hoʻokahi-phase/ʻekolu-phase, MCB/RCD hoʻohui, nā mea kūʻai

Kalepa

≤630A

ʻEkolu mahele mahele, nā papa hoʻokaʻawale, nā ana

ʻOihana

≤6300A

Nā kikowaena hoʻokele kaʻa, ka hāʻawi mana, ka mana kaʻina hana

ʻOihana

≤2500A

Nā mea hoʻohana, nā kikowaena ʻikepili, ka mālama olakino, ka halihali

Hana

wehewehe

Hoʻokō ʻenehana

Mana Loaʻa

E ʻae i ka mana komo mai ka transformer, generator, a i ʻole ka hāʻawi ʻana i luna

ʻO ka mea hoʻokaʻawale kaapuni komo nui (ICB), ka mea hoʻokaʻawale, a i ʻole ka hoʻololi fuse

Māhele Mana

Hoʻokaʻawale i ka mana komo i nā kaapuni lālā he nui

Busbars (ke keleawe/aluminika), nā pahu hoʻolaha, nā mea hoʻomaha kaapuni

Kaapuni Kaapuni

Pale aku i nā kaumaha nui, nā pōkā pōkole, a me nā hewa honua

MCB, MCCB, RCD, RCBO, fusegear

Kaʻawale

Hāʻawi i kahi palekana palekana no ka mālama

Pākuʻi nui, nā mea hoʻokaʻawale me nā mea pili i ʻike ʻia

Nānā & Hoʻomalu

Nā ana, nānā, a hoʻomalu i nā ʻāpana uila

ʻO nā mika ikehu, nā mea nānā pono mana, nā mākaʻikaʻi mamao, nā mea wāwahi akamai

ʻAno mana

Ka pale ʻana i ka piʻi ʻana, ka kānana harmonic, ka hoʻoponopono ʻana i ka mana

ʻO nā SPD, nā kānana hana, nā panakō capacitor

ʻĀpana

Hōʻike

Nā Kūlana Mea

Mea Pahu Busbar

Ke keleawe paʻakikī (C11000) a i ʻole ke alumini alumini (6101-T6)

ASTM B187, IEC 60428

ʻO ka Density o kēia manawa

1.0-1.6 A/mm² (keleawe), 0.8-1.2 A/mm² (alumini)

Ua kaupalena ʻia ka piʻi ʻana o ka mahana i 65K (ʻaʻohe), 80K (plated)

Kaapuni Pokole ke ku

10kA-100kA no 1s (Icw)

IEC 61439-1, hōʻoia ikaika a me ka wela

Lapaʻau ʻili

ʻO ka pāpale tin (8-12μm) a i ʻole ka uhi kālā (3-5μm)

ʻO ke kūpaʻa kino, ka hilinaʻi pili

Kākoʻo Insulators

DMC (Dough Molding Compound) a i ʻole SMC (Sheet Molding Compound)

IEC 60168, helu helu helu>600V

Hoʻonohonoho Busbar

3-phase + N + PE, a i ʻole 3-phase + N (kaʻawale)

ʻO ke kaʻina hana L1-L2-L3, hema loa a ʻākau paha

Palapala noi

ʻAno Pūnaehana

Nā kikoʻī maʻamau

Koi Koi

Na Hale Noho

Mea kūʻai, māhele hale

≤250A, IP40, paʻa i ka paia, 12-24 modules, MCB+RCD

Palekana no ka poʻe maʻamau, hōʻike ʻole ʻia, hōʻailona maopopo

Na Keena Kalepa

Papa hoʻokaʻawale ʻana, papa ʻaina

≤400A, IP30-IP54, paia/papa, 36-72 modules, ana ana

Hiki ke hoʻololi i nā mea hoʻolimalima, sub-metering, hoʻonui i ka wā e hiki mai ana

Nā Hale Kūʻai Kūʻai

Hoʻolimalima hoʻolimalima, māhele nui

≤630A, IP54, kū i ka papahele, modular, nānā akamai

Loaʻa kiʻekiʻe, hoʻokele ukana, nānā kikowaena

Nā kikowaena ʻikepili

ʻĀpana hoʻohele mana (PDU), kaʻi ʻana i ke ala kaʻa

≤1600A, IP20, kū i ka papahele, 3N+PE, redundancy

99.999% loaʻa, wela-swappable, nānā mamao

Nā mea kanu ʻoihana

Ke kikowaena mana kaʻa (MCC), ke kikowaena mana

≤6300A, IP42-IP54, kū i ka papahele, Puka 4 kaawale

ʻO ke kūpaʻa pōkole kiʻekiʻe, palekana kaʻa, hoʻohui kaʻina hana

Na Keena Ola

Māhele mana koʻikoʻi, mana kaʻawale

≤800A, IP30, lāʻau lapaʻau, ʻōnaehana ʻōnaehana IT

Ka palekana o ka poʻe maʻi, ka hoʻomau ʻana o ka lako, ka nānā ʻana o ka leakage i kēia manawa

Ikehu Hou

ʻO ka pahu hui pū o ka lā, ka hāʻawi ʻana i ka waiho pila

≤1500V DC, IP65, waho, nānā kaula

ʻO ka pale ʻana i ka hewa DC arc, pani wikiwiki, paʻa kaiapuni

Nā kahua kūkulu

Ka hāʻawi manawaleʻa mana, nā keʻena pūnaewele

≤400A, IP44-IP65, hiki ke halihali, hana ikaika

ʻO ka neʻe ʻana, ka pale ʻana i ka wā, palekana no ka hoʻohana manawa

Ke kahua

Kaʻina hana

Nā Lae Mana Mana

Hana Metala Pepa

ʻO ke kila i hoʻoheheʻe ʻia (CRCA) a i ʻole ka pepa alumini, ka ʻoki ʻana i ka laser, ke kuʻi ʻana o CNC, ke kuʻi ʻana, ka wili

Ka hoʻomanawanui ʻana ± 0.5mm, nā ʻaoʻao burr-free, weld penetration, flatness <1mm/m

Lapaʻau ʻili

Degreasing, phosphating, electrostatic powder coating (epoxy-polyester), curing (180-200°C/20min)

ʻO ka mānoanoa uhi 60-80μm, hoʻāʻo 0-1 adhesion cross-cut, paʻakai paʻakai 500-1000h

Hoʻoponopono Busbar

ʻOki ʻoki, kuʻi, kuʻi ʻana, ka ʻīni / kala kala, ka pale ʻana

Conductivity ≥100% IACS (ke keleawe), ka mānoanoa o ka uhi ʻana he 8-12μm, ʻaʻohe burrs, hoʻopuni ka ʻaoʻao.

Ke kau ʻana o nā mea

Hoʻokomo ʻia ke kaʻaahi DIN, kau ʻana i ka mea hoʻoheheʻe kaapuni, pili busbar, hoʻopaʻa ʻia i ka torque

Torque no ka mea hana spec (1.5-5.0Nm), alignment, clearance/creepage verification

Uea Kuloko

Nā kaula keleawe (H05RR-F, H07RN-F), hoʻopau ferrule, kala kala (L1-brown, L2-ʻeleʻele, L3-hinahina, N-uliuli, PE-'ōmaʻomaʻo/melemele)

ʻO ka hoʻomau ʻana i ka hoʻāʻo ʻana, ke kūpaʻa insulation> 1MΩ, ka phasing pololei

Hooia Ahahui

ʻO ka hana mīkini, pani puka, hoʻopaʻa, hōʻailona, ​​palapala

100% nānā hana, hōʻoia IP, hoʻokō me IEC 61439-1

Hoao & Hooia

ʻO ka ho'āʻo dielectric (2kV / 1min), ke kūpaʻa insulation, ka hoʻomau, ka polarity, ke kaʻina hana.

ʻO ka hōʻoia maʻamau no IEC 61439-1, hōʻike hōʻike hōʻike

Nānā Hope

Nānā ʻike maka, nānā dimensional, loiloi palapala, hōʻailona hōʻoia

Hōʻike o ka conformity, faila ʻenehana, manual hoʻonohonoho

ʻāpana

Mea kiko'ī

Nā Kūlana Mea Hoʻolako

Na Waiwai Ki

Kino Paʻa

ʻO ke kila ʻōwili anuanu SPCC (1.0-2.0mm) a i ʻole aluminika 5052-H32 (1.5-3.0mm)

JIS G 3141, ASTM B209

ʻO ka ikaika ≥180MPa, ke kūpaʻa magnetic (ke kila), ke kūpaʻa ʻino (Al)

ʻO ka pauka

Epoxy-polyester hybrid, RAL 7035 (hinahinahina māmā) a i ʻole RAL 7032 (hinahina ʻiliʻili)

ISO 12944, Qualicoat

ʻO ka mānoanoa 60-80μm, ʻālohilohi 60-80%, ke kūpaʻa hopena> 50cm·kg

ʻO nā pahu pahi

Electrolytic copper T2 (Cu-ETP, ≥99.9%) aiʻole aluminika 6101-T6

ASTM B187, IEC 60428

Ka hoʻokō ≥100% IACS (Cu), ≥55% IACS (Al), ʻoʻoleʻa HV 80-120

Kākoʻo Busbar

DMC (Dough Molding Compound) a i ʻole SMC (Sheet Molding Compound)

IEC 60168, UL 94 V-0

Helu helu helu >600V, pale wela 180°C, ikaika wili>150MPa

Kaʻaahi DIN

Ke kila ( zinc-plated) a i ʻole alumini (anodized), TH35 (35mm × 7.5mm)

IEC 60715, EN 50022

ʻO ka pololei <0.5mm/m, hiki ke hoʻouka> 100N, kū'ē i ka corrosion

Na Sila Puka

EPDM rubber or polyurethane foam, profile gasket

ASTM D2000, UL 50

Ka wela wela -40°C a +120°C, hoʻonohonoho hoʻoemi <25%, hoʻopaʻa ʻia IP65

Hinges & Laka

Zinc alloy (ZDC) a i ʻole ke kila kila 304, i uhi ʻia i ka chrome

ASTM B86, ISO 9227

ʻO ka paʻakai paʻakai 240-500h, ke ola pōʻaiapuni> 10,000 mau hana, ke kū'ēʻana

Nā ʻĀpana Uila

Polyamide (PA66) a i ʻole keleawe i uhi ʻia i ka nickel, IP68

IEC 62444, UL 514B

ʻO ka mahana -40 ° C a + 100 ° C, hoʻomaha hoʻomaha, koho pale EMC

Nā mea hoʻopololei

PET (Mylar), PVC, a i ʻole nomex no ka pale ʻana i ka busbar

IEC 60216, UL 94 V-0

Ka ikaika dielectric >15kV/mm, helu helu wela>130°C

Kūlana

ʻĀpana

Koi pili

IEC 61439-1:2020

Nā lula maʻamau no nā hui hoʻololi haʻahaʻa haʻahaʻa a me nā hui hoʻokele

ʻO ke kūlana kumu, hōʻoia hoʻolālā, hōʻoia maʻamau, piʻi ka mahana, kū i ke ala pōkole

IEC 61439-3:2024

Hoʻohana ʻia nā papa hoʻolaha e nā kānaka maʻamau (DBO)

Home / kalepa, ≤250A, ≤300V i ka honua, palekana no ka poʻe ʻoihana ʻole.

IEC 61439-2:2011

Nā mea hoʻololi mana a me nā hui hoʻokele

ʻOihana, hoʻohana ʻoihana wale nō, a hiki i 6300A

IEC 61439-4:2023

ʻO nā hui no nā kahua kūkulu (ACS)

Nā mea hoʻonoho manawa, hiki ke lawe ʻia, kūkulu paʻa

IEC 61439-6:2012

Pūnaehana kaʻa kaʻa (nā ala kaʻa)

Ka hāʻawi ʻana i ka mana ma o nā busbars, piʻi nui, nā ʻāpana tap-off

IEC 61439-7:2014

Nā noi kikoʻī (marinas, EV charging, etc.)

Nā kaiapuni kūikawā, nā koi palekana hou

IEC 62208:2011

Nā pā hakahaka no nā hui hoʻololi uila haʻahaʻa

ʻO ka hana paʻa, ka palekana o ke kaiapuni, ka ikaika mechanical

IEC/TR 60890:2014

Hōʻoia ka piʻi wela ma ka helu ʻana

ʻOkoʻa no ka hoʻāʻo ʻana, ka hoʻohālike wela

IEC/TR 61439-0:2013

He alakaʻi no ka wehewehe ʻana i nā hui

Nā kikoʻī o ka mea hoʻohana, nā ʻāpana pili

ʻAno hōʻoia

Ho'āʻo/helu

Koina ʻae

Hōʻoia Manaʻo (Hoʻāʻo ʻAno)

Nā palena piʻi wela

Nā Terminals ≤80K (pale), ≤65K (ʻaʻohe); Hoʻopili ≤40K; Busbars no kēlā me kēia mea

ʻO ka pōkole kū i ka ikaika

Icw no 1s, Ipk peak current, ʻaʻohe deformation, ʻaʻohe pilikia, hana ma hope o ka hoʻāʻo

Nā waiwai dielectric

2kV-3.5kV/1min mana alapine, ʻaʻohe haki, ʻaʻohe flashover

Hoʻomaʻemaʻe a me nā mamao kolo

No ka pollution degere, helu ʻia ka impulse e kū i ka uila

Hana mīkini

200-1000 mau hana, ʻaʻohe lole nui, koi ikaika

Degere o ka palekana (IP)

Ka hōʻoia ʻana o ka code IP (lehu, wai), IEC 60529

Kū'ē i ka corrosion

ʻO ka paʻakai, ka haʻahaʻa, ʻaʻohe degradation e pili ana i ka palekana

Hōʻoia maʻamau (nā ʻāpana āpau)

Ka pololei o ka uwea, ka hana hana

Ka hoʻomau, polarity, phasing, mechanical function

Hoʻāʻo dielectric

1kV-2kV/1s a i ʻole 2U+1000V, ʻaʻohe haki

Kūleʻa hoʻokaʻawale

≥1000Ω/V ma 500V DC

Nā hana pale, hoʻomau uila

≤0.05Ω ma waena o nā ʻāpana conductive i hōʻike ʻia a me ka pahu PE

Mea waiwai

Nā mea nānā

Hoʻolālā Laʻana

Mea lako

ʻO nā lau kila

ʻO ka mānoanoa, ka ikaika hua, ka maikaʻi o ka ʻili, ka hoʻopili ʻana i ka uhi

I kēlā me kēia pūʻulu, COA + hoʻāʻo

ʻO ka mea hōʻike tensile, ka ana mānoanoa o ka uhi ʻana, ka mea hōʻike piʻo

Nā pepa alumini

Alloy grade, mānoanoa, anodizing maikaʻi

I kēlā me kēia pūʻulu

Spectrometer, micrometer, mea hōʻike mānoanoa anodizing

ʻO nā pahu pahu keleawe

Maʻemaʻe, conductivity, paʻakikī, hoʻomanawanui dimensional

I kēlā me kēia pūʻulu

ʻO ka mika conductivity, ka mea hōʻike paʻakikī, CMM

Ka uhi pauda

Pāʻani kala, ʻōlinolino, degere cure, mānoanoa

I kēlā me kēia pūʻulu

Meka ʻālohilohi, mika lapaʻau, ana mānoanoa, spectrophotometer kala

Nā mea palaki

Hiki ke hoʻā ʻia (UL 94), ka helu helu ʻana, ke kūpaʻa ʻana

I kēlā me kēia pūʻulu

UL 94 mea ho'āʻo, ho'āʻo ho'āʻo, hōʻike hōʻike wela

Kūlana

Nā ʻāpana hoʻomalu

Ka pinepine

Kaʻina hana

ʻoki ʻoki/kuʻi laser

ʻO ka pololei o ke ana ± 0.2mm, ka maikaʻi o ka lihi, ke kiʻekiʻe burr

I kēlā me kēia 30 minuke

CMM, nānā maka, micrometer

Kulou

ʻO ka pololei o ka angle ± 0.5°, radius piko, pohā ʻili

ʻO kēlā me kēia hoʻonohonoho + laʻana

Anana kihi, ana radius, nana nana

wiliwili

ʻO ke komo ʻana, ka hiʻohiʻona bead, ka mana distortion

ʻO kēlā me kēia hui weld

ʻO ka nānā ʻana i ka ʻike maka, ka mea hoʻonaninani, X-ray (koʻikoʻi)

Ka uhi pauda

Kiʻiʻoniʻoni mānoanoa 60-80μm, ho'ōla papa manawa, waihoʻoluʻu kūlike

ʻO kēlā me kēia pūʻulu

Ana mānoanoa, mika lapaʻau, hoʻohālikelike kala

Ka hana ʻana i ka busbar

ʻO ka lōʻihi o ka ʻoki ʻana, ke ʻano puka, ka mānoanoa o ka uhi ʻana, ka pōʻai ʻaoʻao

ʻO kēlā me kēia ʻāpana

CMM, XRF ka mānoanoa hoʻoheheʻe ʻia, nānā ʻike

Ahahui

ʻO ka hoʻouka ʻana o nā mea hoʻohui, hoʻopololei, mamao hoʻomaʻemaʻe

ʻO kēlā me kēia ʻāpana

ʻO Torque wrench, nā poloka ana, ka nānā maka

Mea hoao

Kūlana

Laʻana Laʻana

Hōʻoia manaʻo

Nā ana holoʻokoʻa, alignment puka, puka kau

100%

Hōʻoia helu IP

Hoʻopaʻa paʻa, hoʻopaʻa ʻia i ka gasket, pani puka

AQL 1.0 (laana)

ʻO ka dielectric kū i ka hoʻāʻo

2kV AC/1min (mau kaapuni nui), 1kV AC/1min (kokua)

100%

Kūleʻa hoʻokaʻawale

≥1MΩ @ 500V DC

100%

Ka hoʻomau o nā kaapuni pale

≤0.05Ω ma waena o nā wahi PE

100%

Polarity a me ka phasing hōʻoia

Pololei ma na pauku a pau

100%

Hana mīkini

ʻO ka puka, nā laka, nā ʻeke, nā ʻāpana hiki ke huki ʻia

100%

Nānā maka

ʻO nā hemahema ka uhi ʻana, ka lepili, ka maʻemaʻe

100%

Nānā palapala

Nā kiʻi wili, hōʻike hōʻike, hōʻike conformity

100%

Hoʻopaʻa paʻa

Pale i ka wā o ka lawe ʻana, nā ʻōlelo kuhikuhi

Ma ka hailona

Māhele Lako

ʻIkepili mīkini

Hana

Ka hiki

Ka Hana Metala Pepa

ʻoki laser CNC

ʻOki pololei, nā ʻaoʻao paʻakikī, nā ʻaoʻao ʻole burr

10 tona/lā

Kuʻi CNC

Hole patterns, louvers, embossing

5,000 panels / lā

Paʻa paʻi CNC

Piʻo pololei, nā geometries paʻakikī

2,000 mau paʻi / lā

Lapaʻau ʻili

Laina pani pauda maʻemaʻe

Pretreatment, noi pauda, ​​ho'ōla

5,000 m²/lā

Hoʻoponopono Busbar

ʻO ka mīkini kuʻikuʻi/piʻo ʻana i ka pahi ʻo CNC

ʻOki, kuʻi, kuʻi, hoʻopalapala

2,000 busbar set / lā

Laina Hui

Nā kikowaena hui modular, pale ESD, ka nānā ʻana i ka torque

Ke kau ʻana i nā mea, uwila, hoʻāʻo

1,000 pahu hoʻolaha/lā

Lako Hoao

Pahu hoʻāʻo ʻokoʻa (dielectric, insulation, hoʻomau)

Ka hōʻoia maʻamau no IEC 61439

500 mau ʻāpana / lā

ʻO ka hoʻonohonoho hoʻāʻo piʻi ʻana o ka mahana (i kēia manawa a hiki i 6300A)

Hōʻoia hoʻolālā, hoʻāʻo ʻano

10 hoʻonohonoho / mahina

Māhele Huahana

Hiki i kēlā me kēia mahina

Manawa alakai maʻamau

Hiki ke kauoha koke

DBO noho (≤250A, paʻa i ka paia)

50,000 ʻāpana

4-5 wikiwiki

3 lā

Māhele ʻoihana (≤630A, papahele/pā)

20,000 ʻāpana

4-5 wikiwiki

5 lā

Nā kikowaena mana ʻoihana (≤2500A, kū i ka papahele)

5,000 ʻāpana

4-5 wikiwiki

7 lā

ʻO nā hāʻina i hana ʻia (≤6300A)

Kumu papahana

4-8 pule

2-3 pule

Pūnaehana busbar modular

10,000 mika

4-5 wikiwiki

5 lā

Oihana

Paahana

ʻike

Nā kuleana

R&D 'enekinia

5

 nā ʻenekinia

IEC 61439 hoʻokō, hoʻohālike wela, helu pōkole pōkole, ʻepekema waiwai

Hoʻomohala huahana hou, hoʻolālā hoʻolālā, kōpili patent (40+ mau patent)

Kaʻina Hana Hana

25 ʻenekinia

ʻO ka hana ʻana i ka lau metala, ka mālama ʻana i ka ʻili, ka hana ʻana i ka busbar, ka hana lean

Hoʻonui i ka hana, automation, hoʻomaikaʻi i ka hua (> 98%), hoʻemi i ke kumu kūʻai

Ka ho'āʻo a me ka hōʻoia

20 ʻenekinia

IEC 61439 hōʻoia, hoʻāʻo piʻi wela, hoʻāʻo pōkole pōkole, EMC

ʻAno hoʻonohonoho hoʻāʻo, hōʻoia maʻamau, hōʻoia ʻole, hōʻoia

Hoʻohana ʻenehana

15 enekinia

Hoʻolālā ʻōnaehana mana, hoʻonohonoho koho, nānā hoʻonohonoho, hoʻonohonoho

Kākoʻo ʻenehana mea kūʻai aku, hoʻolālā hoʻolālā, nānā pūnaewele, aʻo

Hōʻoia maikaʻi

35 mau ʻenehana

ISO 9001, ISO 14001, kaʻina kaʻina hana helu, ʻoihana metrology

Hoʻoponopono ka mea hoʻolako, loiloi kaʻina hana, hana hoʻoponopono, hoʻokele calibration
